DMX



3 Channels
Channel 1	000-255	Red 0-100%
Channel 2	000-255	Green 0-100%
Channel 3	000-255	Blue 0-100%
9 Channels
Channel 1	000-255	Dimmer 0-100%
Channel 2	000-255	Red 0-100%
Channel 3	000-255	Green 0-100%
Channel 4	000-255	Blue 0-100%
Channel 5	000-010	No Function
	011-255	Color Macros
Channel 6	000-010	No Function
	011-255	Strobe Speed (Slow - Fast)
Channel 7	000-010	No Function
	011-016	Auto Program 1
	017-022	Auto Program 2
	023-028	Auto Program 3
	029-034	Auto Program 4
	035-040	Auto Program 5
	041-046	Auto Program 6
	047-052	Auto Program 7
	053-058	Auto Program 8
	059-064	Auto Program 9
	065-070	Auto Program 10
	071-076	Auto Program 11
	077-082	Auto Program 12
	083-088	Auto Program 13
	089-094	Auto Program 14
	095-100	Auto Program 15
	101-106	Auto Program 16
	107-112	Auto Program 17
	113-118	Auto Program 18
	119-124	Auto Program 19
	125-130	Auto Program 20
	131-136	Auto Program 21
	137-142	Auto Program 22
	143-148	Auto Program 23
	149-154	Auto Program 24
	155-160	Auto Program 25
	161-166	Auto Program 26
	167-172	Auto Program 27
	173-178	Auto Program 28
	179-184	Auto Program 29
	185-190	Auto Program 30
	191-196	Auto Program 31
	197-202	Auto Program 32
	203-208	Auto Program 33
	209-214	Auto Program 34
	215-220	Auto Program 35 (Programs 1-8, Loop
	221-226	Auto Program 36 (Programs 9-15, Loop
	227-232	Auto Program 37 (Programs 16-26, Loop
	233-238	Auto Program 38 (Programs 35-37, Loop
	239-255	Sound Active Program
Channel 8	000-255	Speed Adjustment Channel 7 (Slow - Fast)
	000-010	Sound Senetivity Off
	011-255	Adjust the Senitivity level
Channel 9	000-051	Dimmer Speed Set by Display Menu
	052-101	Dimmer Speed Off
	102-152	Dimmer Speed Mode 1 (Fast)
	153-203	Dimmer Speed Mode 2
	204-255	Dimmer Mode 3 (Slow)
60 Channels
Channel 1	000-255	LED 1 - Red - 0-100%
Channel 2	000-255	LED 1 - Green - 0-100%
Channel 3	000-255	LED 1 - Blue - 0-100%
Channel 4	000-255	LED 2 - Red - 0-100%
Channel 5	000-255	LED 2 - Green - 0-100%
Channel 6	000-255	LED 2 - Blue - 0-100%
Channel 7	000-255	LED 3 - Red - 0-100%
Channel 8	000-255	LED 3 - Green - 0-100%
Channel 9	000-255	LED 3 - Blue - 0-100%
Channel 10	000-255	LED 4 - Red - 0-100%
Channel 11	000-255	LED 4 - Green - 0-100%
Channel 12	000-255	LED 4 - Blue - 0-100%
Channel 13	000-255	LED 5 - Red - 0-100%
Channel 14	000-255	LED 5 - Green - 0-100%
Channel 15	000-255	LED 5 - Blue - 0-100%
Channel 16	000-255	LED 6 - Red - 0-100%
Channel 17	000-255	LED 6 - Green - 0-100%
Channel 18	000-255	LED 6 - Blue - 0-100%
Channel 19	000-255	LED 7 - Red - 0-100%
Channel 20	000-255	LED 7 - Green - 0-100%
Channel 21	000-255	LED 7 - Blue - 0-100%
Channel 22	000-255	LED 8 - Red - 0-100%
Channel 23	000-255	LED 8 - Green - 0-100%
Channel 24	000-255	LED 8 - Blue - 0-100%
Channel 25	000-255	LED 9 - Red - 0-100%
Channel 26	000-255	LED 9 - Green - 0-100%
Channel 27	000-255	LED 9 - Blue - 0-100%
Channel 28	000-255	LED 10 - Red - 0-100%
Channel 29	000-255	LED 10 - Green - 0-100%
Channel 30	000-255	LED 10 - Blue - 0-100%
Channel 31	000-255	LED 11 - Red - 0-100%
Channel 32	000-255	LED 11 - Green - 0-100%
Channel 33	000-255	LED 11 - Blue - 0-100%
Channel 34	000-255	LED 12 - Red - 0-100%
Channel 35	000-255	LED 12 - Green - 0-100%
Channel 36	000-255	LED 12 - Blue - 0-100%
Channel 37	000-255	LED 13 - Red - 0-100%
Channel 38	000-255	LED 13 - Green - 0-100%
Channel 39	000-255	LED 13 - Blue - 0-100%
Channel 40	000-255	LED 14 - Red - 0-100%
Channel 41	000-255	LED 14 - Green - 0-100%
Channel 42	000-255	LED 14 - Blue - 0-100%
Channel 43	000-255	LED 15 - Red - 0-100%
Channel 44	000-255	LED 15- Green - 0-100%
Channel 45	000-255	LED 15 - Blue - 0-100%
Channel 46	000-255	LED 16 - Red - 0-100%
Channel 47	000-255	LED 16 - Green - 0-100%
Channel 48	000-255	LED 16 - Blue - 0-100%
Channel 49	000-255	LED 17 - Red - 0-100%
Channel 50	000-255	LED 17 - Green - 0-100%
Channel 51	000-255	LED 17 - Blue - 0-100%
Channel 52	000-255	LED 18 - Red - 0-100%
Channel 53	000-255	LED 18 - Green - 0-100%
Channel 54	000-255	LED 18 - Blue - 0-100%
Channel 55	000-255	LED 19 - Red - 0-100%
Channel 56	000-255	LED 19 - Green - 0-100%
Channel 57	000-255	LED 19 - Blue - 0-100%
Channel 58	000-255	LED 20 - Red - 0-100%
Channel 59	000-255	LED 20 - Green - 0-100%
Channel 60	000-255	LED 20 - Blue - 0-100%
